1X18 CWDM Mux Demux Module 1260nm-1620nm Wavelength High Isolation Compact Design

Brand Name : HILINK

Model Number : CCWDM-XX

Certification : CE FCC Rohs

Place of Origin : Guangdong, China

MOQ : 1pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100pcs/week

Wavelength : 1260nm-1620nm

Channel : 18

Channel Spacing : 20nm

Center Wavelength(nm) : ITU, ITU+1

Operating Temperature : -40~85°C

Fiber Length : 1.0m 1.5m or customized

Customerized : Yes

Contact Now

1X18 CWDM Mux Demux Module 1260nm-1620nm Wavelength High Isolation Compact Design

Features
Low Insertion Loss
High Isolation
Low PDL
Compact Design
Good channel-to-channel uniformity
Wide Operating Wavelength
From 1260nm to 1620nm
Wide Operating Temperature
From -40°C to 85°C
High Reliability and Stability


Applications
CWDM System
PON Networks
CATV Links


Performance Specifications

Parameter 4 Channel 8 Channel 18 Channel
Mux Demux Mux Demux Mux Demux
Channel Wavelength (nm) 1270~1610
Center wavelength Accuracy (nm) ±0.5
Channel Spacing (nm) 20
Channel Passband (@-0.5dB bandwidth (nm) >13
Insertion Loss (dB) ≤1.6 ≤2.5 ≤3.0
Channel Uniformity (dB) ≤0.6 ≤1.0 ≤1.5
Channel Ripple (dB) 0.3
Isolation (dB) Adjacent N/A >30 N/A >30 N/A >30
Non-adjacent N/A >40 N/A >40 N/A >40
Inertion Loss Temperature Sensitivity (dB/°C) <0.005
Wavelength Temperature Shifting (nm/°C) <0.002
Polarization Dependent Loss (dB) <0.1
Polarization Mode Dispersion <0.1
Directivity (dB) >50
Return Loss (dB) >45
Maximum Power Handling (mW) 300
Opterating Temperature (°C) -5~+75
Storage Temperature (°C) -40~85
Package dimension (mm) L100 x W80 x H10 or L140xW100xH15




True photo show
1X18 CWDM Mux Demux Module 1260nm-1620nm Wavelength High Isolation Compact Design

1X18 CWDM Mux Demux Module 1260nm-1620nm Wavelength High Isolation Compact Design


Company Information

1X18 CWDM Mux Demux Module 1260nm-1620nm Wavelength High Isolation Compact Design


Packaging & Shipping

International Express: DHL, FedEx,EMS,TNT, UPS and so on. It takes 3-7 days.


Our Services
OEM/ODM order is available
we can supply products according to your requirements, and design products label for your company.
